Dinuy CO KNT IPR -ROUTER KNX IP SECURE
€318,22 Excl. tax
€565,73 Excl. tax
€385,05 Incl. tax €684,53 Incl. tax. Out of stock, but available
€385,05 Incl. tax €684,53 Incl. tax. Out of stock, but available
The KNX IP Secure Router forwards telegrams between different lines via a LAN network and connects a PC to the KNX network for ETS programming. KNX security is activated. Read more
Specifications
Brand:
Dinuy
Article number:
CO KNT IPR
EAN:
8422447017915
Availability:
Out of stock, but available
Delivery time:
Dispatched within approximately 8 working days (please note: this is an estimate and depends on availability from the manufacturer; in some cases, it may be dispatched sooner, but it can also take longer).
Due to the holidays, orders may be delayed and pickup is not possible.
Information
KNX IP Secure Router - Safe and Reliable
The KNX IP Secure Router forwards telegrams between different KNX lines via a LAN (IP) network, serving as a fast backbone. This device allows connecting a PC to the KNX network for ETS programming. The router supports KNX Secure for secure communication.
Key Features
- Forwards telegrams between KNX lines via LAN
- Supports KNX Secure for secure communication
- Suitable for ETS programming via PC connection
- IP address can be configured manually or obtained via DHCP
- Extended filter table for main group 0..31
- Stores up to 150 telegrams
- Power supplied via KNX bus
Technical Specifications
- Power via KNX bus: 29V
- Power consumption: 20mA
- Relative humidity: 5% - 93%
- Temperature range: -25°C to 70°C (storage), -5°C to 45°C (operation)
- Mounting: DIN rail, 1 TE (18 mm)
- Protection level: IP20 according to EN60529
- Directives: EMC 2014/30/UE, RoHS 2011/65/UE
