The iONprime CP4 KNX is a room controller with a 4" touch display for temperature, humidity, presence and brightness. Provides up to 6 pages with 8 functions each for switching, dimming, shading and climate control in smart buildings.

Universal 8-channel dim actuator, 200 W/channel, for R, L, C loads. Supports LED, halogen, CFLs, and fans. With manual control and LED status indication.

DALI-2 KNX gateway with 2 channels for 64 DALI drivers each. (16) groups, scenes, DT8 color control, effects, and easy setup via free ETS DCA app.

Line and area coupler for KNX installations. Connects backbone, areas and subordinate lines and provides telegram filtering functions. Supports secure data exchange via Secure Proxy and can be used as a segment coupler with ETS 6.

Digital timer with annual and astro program, 8 channels, DCF/GPS time sync, 800 memories, holiday, pulse and cycle program, KNX and mains power, DIN rail.

For mounting 1 or 2 Meteodata, LUXOR or LUNA weather stations to a pole or outdoor corner (diameter 48–60 mm).

Base device for 2/4/8-way operation. Compatible with iONprime keycaps in 3 variants (1-, 2-, 4-gang) and 7 colours/materials with a high-quality appearance and pleasant haptics. Keycaps are sold separately.

4-gang push button cover for the iONprime PB KNX push button base unit. Made of metal or high-quality plastic with premium finish and clear button layout. Easy installation thanks to secure click-on mounting.

Outdoor PIR motion detector for wall or ceiling mounting. Automatic light control based on presence and brightness. Easy KNX integration via ETS.

Overvoltage protection for KNX or LUXORliving systems. Protects bus couplers from surges. Easy to install in place of the bus terminal.

2-gang push button cover for the iONprime PB KNX push button sensor base module. Made of metal or high-quality plastic with a premium finish and pleasant tactile feel. Clear button layout and easy click-in mounting.

Glass KNX touch sensor with 2 buttons, 2 configurable status LEDs and integrated temperature sensor. Supports KNX Data Secure and controls switching, dimming, blinds, scenes and more.

Twilight switch with external light sensor. 10 channels, 4 threshold, 6 logic channels, manual control, display lighting and PIN security.

Sensor for CO2, temperature, humidity and air pressure. With 3 adjustable thresholds, room temperature control, 4 binary inputs and multicolour LED indication. KNX wall mounting.

IR gateway for controlling split air conditioners via KNX. Easy to configure, with a large database of over 500 supported units.

Interface between OT bus heating systems and KNX. Supports up to 10 zones, domestic hot water control, energy optimization, drying and legionella protection programs.

Fan coil actuator for 2- and 4-pipe systems with 3 fan speeds, 0–10 V control, relay output, condensate monitoring, manual control, and temperature compensation.

Weather station for wind, rain, brightness and temperature. Automatic shading for up to 8 façades, with rain sensor and KNX integration.

DALI gateway for integrating up to 64 DALI devices into KNX systems. Supports group and scene control, color management (DT8), emergency lighting, display and web server.

PIR motion detector for flush wall mounting with 170° detection, 14x17 m range. 1 light and 1 HVAC channel, dimmable, KNX Data Secure, ETS-compatible.

DALI-2 certified gateway with 1 channel for 64 DALI luminaires. (16) groups, (16) scenes, effects, color control (DT8). Easy setup and ballast replacement via ETS DCA.

Outdoor light sensor for KNX systems, measuring 1 to 100,000 lux. Ideal for brightness-dependent control. Can be combined with the Theben weather station.

8-fold KNX push-button interface with Data Secure, temperature measurement, LED control and flexible functions. Suitable for flush mounting with standard switches.

6-fold KNX push-button interface for binary input/output with KNX Data Secure, temperature measurement, LED control and flexible function assignment.
