DINUY IT KNT 004 4-channel switching/blind actuator with 12 inputs
€135,34 Excl. tax
€240,60 Excl. tax
€163,76 Incl. tax €291,13 Incl. tax. In stock (2)
€163,76 Incl. tax €291,13 Incl. tax. In stock (2)
4-channel Multi-function Switching Actuator or 2-channel Blinds/Shutters Actuator.
Incorporates 12 Inputs: 8-Binary Inputs + 4-Binary/Analog Inputs. Read more
Specifications
Brand:
Dinuy
Article number:
IT KNT 004
EAN:
8422447015010
Availability:
In stock (2)
Delivery time:
1-3 working days
Information
Description:
4-channel Multi-function Switching Actuator or 2-channel Blinds/Shutters Actuator. High load capacity, with 16A built-in relays, as well as a zero-crossing-point control, which allows switching very high loads, even capacitive type. Incorporates 12 Inputs: 8-Binary Inputs + 4-Binary/Analog Inputs. These inputs can be independently parameterized through the ETS Software: · Binary Input: allows the connection of a conventional voltage-free binary sensor or switch. · Analog Input: allows the connection of a DINUY temperature probe (ST KNT 001 or ST KNT 002). Incorporates a front keypad for independent manual control of each output, as well as status indicator LEDs. Allows to enable and configure up to 4 independent Heating and / or Cooling Thermostats. It incorporates 8 Logic Functions, Centralized Control, Scenes, Time Function, etc. Possibility of connecting different phases in each output channel. DIN-rail mounting, 4 modules wide. Programming and commissioning via ETS5 or later versions.
| Technical characteristics IT KNT 004 | |
| Product reference | IT KNT 004 |
| Power Supply (V) | 230VCA |
| Frequency (Hz) | 50 |
| Consumption | 7mA |
| Output channels | 4 |
| Switching capacity (A) | 16 |
| Type of load | 4 Switch or 2 Blind channels |
| LED lamps load (W) | 400 |
| Incandescent and Halogen 230V (W) | 3000 |
| 12V Halogen with electronic transformer (W) | 3000 |
| Motores (VA) | 700 |
| Maximum current input 1/10VDC (mA) | 0 |
| Maximum Number of Equipments | 0 |
| Contacts | Voltage-free |
| Binary/Analogic Inputs | 12 |
| Installation | DIN Rail |
| Module number | 4 |
| Control | KNX Bus |
| Programming by | ETS5 o posterior |
| Compatible with | KNX |
| Connection terminals | Captive Screws |
| Cable section (mm2) | 2.5 |
| Minimum Storage Temperature (ºC) (min) | -30 |
| Maximum Storage Temperature (ºC) (max) | 70 |
| Minimum Working Temperature (ºC) (min) | -5 |
| Maximum Working Temperature (ºC) (max) | 45 |
| Protection Degree | IP20 , UNE 20324 |
| According with Directives | Low-voltage 73/23/EEC // EMC 204/108/EC |
| According to the Standard | KNX Standard 2.0 // EN60669-1, 2-1 & 2-3 |
