8-fold Blind Actuator 8A, 230VAC up to 300W

0 Review(s)

€270,40 Excl. tax €416,00 Excl. tax
€327,18 Incl. tax €503,36 Incl. tax. Not in stock in our warehouse, but available to order.

Unit price: €270,40 / Piece

Shutter Actuator JAL-0810.02, 8-fold, supports 230VAC motors up to 300W. Features include automatic sun shading, travel and stop settings, manual operation with LED indicator, and priority options. Read more

Specifications

Brand:

MDT

Article number:

JAL-0810.02

EAN:

4251916130633

Availability:

Not in stock in our warehouse, but available to order.

Delivery time:

Dispatched within approximately 10 working days (please note: this is an estimate and depends on availability from the manufacturer; in some cases, it may be dispatched sooner, but it can also take longer).

Information

Datasheet

JAL-0810.02 Shutter Actuator 8-fold

The JAL-0810.02 8-fold Shutter Actuator is designed for precise and reliable control of shutters and sunshades. The device offers a range of advanced functions that go beyond simple up-and-down movements. With automatic sun position calculation, the actuator dynamically regulates sunlight, enabling energy savings and comfort optimization.

Main Features

Automatic sun position calculation for efficient shading
Manual operation with LED indicators for each channel
Adjustable travel times for precise positioning
Extended alarm, central, and blocking functions
Scene control and absolute positioning via 1 Byte
Robust mechanical lifespan of 1,000,000 cycles per channel

Technical Specifications

Number of channels	8
Voltage	230VAC
Maximum load per channel	300W
Protection class	IP 20
Dimensions	8SU
Operating temperature range	0 to +45°C

The JAL-0810.02 comes with a 3-year warranty and is manufactured in Germany according to ISO 9001 certification. For project design and commissioning, ETS software is recommended, available for download from the official MDT website.
