P360 KNX AP Multi WH – Multisensor for KNX Systems

Name: Theben P360 KNX AP Multi WH – Multisensor for KNX Systems
Brand: Theben
Price: 224.22 EUR
Availability: OutOfStock
Rating: 0 (0 reviews)

0 Review(s)

€224,22 Excl. tax €389,94 Excl. tax
€271,31 Incl. tax €471,83 Incl. tax. Out of stock, but available

Unit price: €224,22 / Piece

KNX multisensor: detects presence, measures CO2, temperature, humidity and air pressure. 360° detection area, 4 binary inputs and integrated thermostat. For ceiling mounting. Read more

Specifications

Brand:

Theben

Article number:

2079900

EAN:

4003468200414

Availability:

Out of stock, but available

Delivery time:

Dispatched within approximately 8 working days (please note: this is an estimate and depends on availability from the manufacturer; in some cases, it may be dispatched sooner, but it can also take longer).

Information

Link to Theben website

thePrema P360 KNX AP Multi WH – Multisensor

Art. no.: 2079900

Application

The thePrema P360 KNX AP Multi WH is an advanced KNX multisensor designed for ceiling mounting in offices, schools, meeting rooms, hospitals and other smart building environments. By combining a passive infrared presence detector and a room air sensor, this device provides a comprehensive solution for efficient climate and lighting control.

Main Features

KNX Multisensor: Consists of a KNX passive infrared presence detector and a room air sensor (two separate bus devices).
Room Air Sensor Functions:
- Measures CO₂ concentration (300 – 5000 ppm)
- Measures relative humidity (1 – 100 % RH)
- Measures temperature (-5°C ... 45°C)
- Measures air pressure (30,000 – 110,000 Pa)
- Three independently adjustable thresholds for CO₂ concentration and humidity
- Integrated room thermostat
- Four binary inputs
Presence Detector Functions:
- 360° square detection area (up to 100 m², 9 x 9 m)
- Three light channels (C1, C2 with light measurement, additional channel C3 without light-dependent switching)
- Two independently adjustable presence channels
- Adaptive 3-channel light measurement (suitable for LEDs, fluorescent, halogen, and incandescent lamps)
- Fully or semi-automatic operation, easily switchable
- Operating mode: switching or constant light control with standby function
- Dimmable lighting possible in switching mode with standby function
- Light threshold or setpoint adjustable in Lux via parameter, object or remote control
- Teach-in function for light threshold or setpoint
- Adjustable room correction factor for light measurement
- Light follow-up time adjustable (30 s – 60 min) via parameter, object or remote control
- Switch-on delay and follow-up time for presence adjustable
- Adjustable detection sensitivity
- Self-learning follow-up time and function for shortening in case of short presence
- Scene functions for flexible applications
- Easy energy saving with "eco plus" function
- Test mode for checking operation and detection area
- Parallel connection of multiple detectors (Master/Slave or Master/Master possible)
- User and service remote control (optional)
- Room surveillance function

Technical Specifications

Mounting height	2 – 10 m (min. 1.7 m)
Detection area	81 m² (9.0 x 9.0 m), square, 360°
Light measurement range	5 – 3000 lux
Light follow-up time	30 s – 60 min (adjustable)
Presence follow-up time	10 s – 120 min (adjustable)
Presence switch-on delay	10 s – 30 min or inactive
Lamp types	Energy-saving lamps, fluorescent lamps, incandescent and halogen lamps, LEDs
Type of light measurement	Mixed light measurement (suitable for various light sources)
CO₂ measurement range	300 – 5000 ppm
Temperature range	-5°C ... +45°C
Air pressure measurement range	30,000 – 110,000 Pa
Humidity measurement range	1 – 100 % RH
Interface extension	max. 30 m
Protection class	IP 20
Ambient temperature	5°C ... 40°C
Colour	White

Important Notes

This device consists of two separate KNX bus devices: a presence detector and a room air sensor.
For warranty conditions, see: www.theben.de/en/guarantee
Suitable for indoor use and ceiling mounting only.
