KNX Mini-Presence PD-C360i/12 mini KNX

Name: ESYLUX KNX Mini-Presence PD-C360i/12 mini KNX
Brand: ESYLUX
Price: 91.55 EUR
Availability: OutOfStock
Rating: 0 (0 reviews)

0 Review(s)

€91,55 Excl. tax €149,00 Excl. tax
€110,78 Incl. tax €180,29 Incl. tax. Out of stock, but available

Unit price: €91,55 / Piece

Compact KNX ceiling presence detector with 360° detection and 12 m range. Supports daylight control, alarm, and light functions. Suitable for ceiling flush mount. Read more

Specifications

Brand:

ESYLUX

Article number:

EP10426162

EAN:

4015120426162

Availability:

Out of stock, but available

Delivery time:

Dispatched within approximately 8 working days (please note: this is an estimate and depends on availability from the manufacturer; in some cases, it may be dispatched sooner, but it can also take longer).

Due to the holidays, orders may be delayed and pickup is not possible.

Information

Datasheet

Manual

ESYLUX KNX Presence Detector PD-C | 360°, 12 m, Mini Ceiling Mount

Compact and advanced KNX ceiling-mounted presence detector with a wide detection range, high sensitivity, and integrated daylight-dependent light regulation.

Key Features

360° detection angle with a range up to 12 m.
Integrated daylight-dependent constant light control.
Advanced KNX functions: Alarm, twilight switch, brightness detection, motion-dependent lighting, and scene telegram via objects.
Operating modes: Semi-automatic and fully automatic.

Technical Specifications

General

Device Category: Ceiling presence sensor
Mounting Variant: Ceiling flush mount
Dimensions: Height/Depth 70 mm, Ø 58 mm
Weight: 71.3 g
Material: UV-stabilized polycarbonate
Color: Opaque matte
Protection Degree: IP55
Operating Temperature: 5 °C to +50 °C
Conformity: CE, EAC, RoHS, AEEA
Warranty: 5 years

Electrical Specifications

Nominal Voltage: 29–31 V DC
Power Consumption: 0.2 W
Current Consumption: 6 mA
Connection Type: Plug, Bus

Detection and Control

Detection Angle: 360°
Detection Range: Up to 12 m (horizontal), 6 m (frontal), 4 m (presence detection)
Brightness Range: 5–2000 lux
Lighting Channels: 2
HVAC Channels: 1
Control Modes: Manual, semi-automatic, fully automatic

Advanced KNX Functions

Presence simulation
Manual operation
Master/slave functionality
Night light function
Adjustable sensitivity

Important Notes

Maintain a safe distance of 5 meters from radio antennas (e.g., Wi-Fi access points) during installation. This product includes a lens mask, spring clips, and mounting accessories for ceiling installation.
