N 141/31 KNX/DALI Gateway Twin

375,84 Excl. tax €696,00 Excl. tax
€454,77 Incl. tax 842,16 Incl. tax.
In stock (1)
Unit price: €375,84
Two DALI outputs with DALI-2 certification acc. to IEC 62386-101 and 103, each for communication with up to 64 DALI ballasts Read more


Article number:
In stock (1)
Delivery time:
1-3 working days




N 141/31KNX/DALI Gateway Twin

  • Communication via KNX EIB with electronic ballasts (ECG) with a DALI interface
  • Two DALI outputs with DALI-2 certification acc. to IEC 62386-101 and 103, each for communication with up to 64 DALI ballasts
  • Integrated power supply with input voltage AC 110...240 V, 50...60 Hz or DC 120...240 V for powering the gateway electronics and DALI output
  • Support of ECGs Type 0, 1, 2, 3, 4, 5, 6, 7 and 8 according to EN 62386 edition 1 as well as edition 2 (DALI-2)
  • Maximum DALI output voltage of 19 V, short circuit resistant
  • Incorrect voltage detection during commissioning, whether incorrect power line is connected to a DALI output
  • LED display for displaying operation mode and error messages
  • Pushbutton for switching between bus and direct operating mode
  • One pair of pushbuttons for switching On/Off of all connected DALI ballasts
  • One LED per DALI output for status signal of all connected luminaries in direct mode
  • Configurable behaviour for bus failure (stand-alone mode)
  • Control (switching, dimming, set dimming value) of all connected luminaries together in broad-cast mode
  • Status signal and display of lamp and ECG failure per group and per DALI device
  • One or two level timer
  • Integrated scene control for up to 32 scenes
  • Assignment of DALI ECG to groups and test option for ECG, groups and scenes via ETS during commissioning
  • Possibility to reintegrate defective DALI ECG without software
  • Integrated bus coupling unit with only half a standard bus load
  • Bus connection via bus terminal
  • Mounting on DIN rail EN 60715-TH35-7.5
Additional functionalities GAMMA
The following options are selectable, depending on the application program:
  • Configurable assignment of max. 128 DALI ECG to max. 32 DALI groups, exclusive controlled in groups or single (switching, dimming, set dimming value and color temperature) and feedback for group status and lamp failure
  • Support of DALI DT8 ECGs for colour temperature control Tc, Tunable White according to EN 62386 part 209. individual, group, scene, effect and schedule control for Human Centric Lighting (HCL)
  • Configurable function burn-in for all ECG via pushbutton or single via object
  • Up to twelve stand-by-area analysis for activation of switch actuators
  • Distinction between self-contained emergency luminaries with one or two DALI devices
  • Optional configuration of any DALI ECG to dim to a preset dimming value in case of emergency mode
  • Locking of switching and dimming commands as well as configuration while emergency mode is activated
  • Activation of emergency mode based on a configurable number of failed DALI ECG
  • Lock object to elimination of failure messages interruption of ECG during emergency lighting testing
  • Inhibit mode for disabling battery mode of self-contained emergency luminaries over pushbutton
