AC IR1 KNX | KNX split unit gateway
€97,13 Excl. tax
€168,92 Excl. tax
€117,53 Incl. tax €204,39 Incl. tax. Out of stock, but available
€117,53 Incl. tax €204,39 Incl. tax. Out of stock, but available
IR gateway for controlling split air conditioners via KNX. Easy to configure, with a large database of over 500 supported units. Read more
Specifications
Brand:
Theben
Article number:
4940320
EAN:
4003468492086
Availability:
Out of stock, but available
Delivery time:
Will be shipped within approximately 8 working days.
Information
AC IR1 KNX | KNX Split Unit Gateway for IR air conditioner control
Art. No.: 4940320
Product Description
The AC IR1 KNX by Theben is a compact KNX gateway for controlling split air conditioning units via infrared. Thanks to its integrated and constantly expanding database with over 500 supported models, commonly used split units can be easily integrated into KNX systems. Quick and easy setup via ETS. Suitable for flush-mounted installation.
Applications
- KNX integration of split-type air conditioners using infrared signals
- Home and building automation in residential, office, and hotel environments
- HVAC control via central KNX control panels
- Retrofitting existing AC systems without direct bus connection
Main Features
- Split Unit Gateway for KNX-based control of air conditioners via IR
- Supports over 500 different remote controls and models
- IR database is continuously expanded through firmware updates
- Easy setup and addressing via ETS (Engineering Tool Software)
- Compact design for flush-mounted installation behind switches or in wall boxes
- Optimized for use with standard split AC systems
Technical Specifications
| KNX Supply Voltage | Via KNX bus, < 12 mA |
|---|---|
| Mounting Type | Flush-mounted |
| Number of Channels | 1 channel (IR output) |
| Ambient Temperature | -5 °C to +45 °C |
| Protection Rating | IP20 |
| Protection Class | Class II (double insulation) |
| Dimensions (W x H x D) | Compact format depending on mounting box |
| Configuration | Via ETS (Engineering Tool Software) |
| IR Database | Over 500 supported models (updated regularly) |
Important Notes
- Installation and commissioning only by certified KNX professionals.
- Check compatibility of the AC unit with the IR database before use.
- Not suitable for damp or outdoor environments without additional protection.
- Line-of-sight between the IR gateway and air conditioner is required for proper operation.
- The IR database is regularly updated via firmware.
