KLIC-DA v2 KNX-Daikin Altherma Gateway | ZCLDAV2
€197,53 Excl. tax
€265,49 Excl. tax
€239,01 Incl. tax €321,25 Incl. tax. Out of stock, but available Manual
€239,01 Incl. tax €321,25 Incl. tax. Out of stock, but available Manual
Gateway for KNX-Daikin Altherma units. Bidirectional control, 2 inputs for sensors, 10 logic functions, data saving on power failure. Read more
Specifications
Brand:
Zennio
Article number:
ZCLDAV2
EAN:
8411080789990
Availability:
Out of stock, but available
Delivery time:
Dispatched within approximately 8 working days (please note: this is an estimate and depends on availability from the manufacturer; in some cases, it may be dispatched sooner, but it can also take longer).
Due to the holidays, orders may be delayed and pickup is not possible.
Information
Zennio KLIC-DA v2 KNX-Daikin Altherma Gateway (Ref.: ZCLDAV2)
The Zennio KLIC-DA v2 gateway enables bidirectional control of Daikin Altherma and Altherma 3 units via a KNX system. With 2 analog-digital inputs and 10 logic functions, it offers extensive options for HVAC integration and automation.
Features:
- Bidirectional communication with Daikin Altherma units.
- 2 analog/digital inputs for sensors or switches.
- 10 logic functions for flexible automation.
- Data saving on KNX bus failure.
- Dimensions: 67 x 90 x 36 mm (2 DIN units).
- DIN rail mounting according to IEC 60715 TH35.
- CE compliant.
Technical Specifications:
- Power supply: 21-31 VDC, typical 29 VDC.
- Operating temperature: 0 .. +55 °C.
- Storage temperature: -20 .. +55 °C.
- Humidity: 5% to 95% (non-condensing).
- Protection rating: IP20.
- Weight: 114 g.
Input Specifications:
- 2 inputs for temperature probes, motion sensors, or dry contacts.
- Maximum cable length: 30 m.
- Temperature probe accuracy: ±0.5 °C at 25 °C.
Installation: The module is easy to install on a DIN rail and requires no external power supply. Professional installation is recommended.
Note: Refer to the KLIC-DA v2 compatibility table for use with specific Daikin Altherma units.
