Tecla RGB 55 X6 Touch sensor push button 6-fold KNX Secure
€131,18 Incl. tax €168,18 Incl. tax. Out of stock, but available
Specifications
Information
KNX Touch Sensor Tecla RGB 55 X6
The Tecla RGB 55 X6 is a high-quality capacitive KNX touch sensor featuring six independent touch zones, RGB backlighting and full support for KNX Secure. Its dynamic illumination adapts automatically through the integrated proximity and ambient light sensors. The device also includes a built-in thermostat, internal temperature sensor and two versatile analogue/digital inputs. A powerful and flexible solution for modern KNX installations in both residential and commercial buildings.
Main Features
- 6 capacitive touch zones with RGB backlighting and fully customisable icons.
- Full support for KNX Data Secure.
- Integrated thermostat and internal temperature sensor.
- 2 configurable analogue/digital inputs for sensors, push buttons or external temperature probes.
- Proximity sensor for automatic activation of the backlight.
- Ambient light sensor for intelligent brightness control.
- Acoustic feedback confirming each touch.
- Complete data retention in case of KNX bus failure with automatic recovery.
- Compatible with 55×55 mm frames and Zennio ZS55 switches and sockets.
- Suitable for European, Italian, American and Australian wall boxes.
- Available in white, silver, anthracite, champagne and custom design.
Technical Specifications
| Model | Tecla RGB 55 X6 (ZVITR55X6) |
|---|---|
| Dimensions | 55.5 × 55.5 × 37.3 mm |
| Power Supply | 21–31 VDC (typical 29 VDC) |
| Maximum Consumption |
|
| Internal Temperature Sensor |
|
| Number of Inputs |
|
| Protection Rating | IP20 (indoor use) |
| Operating Temperature | 0 to +55 °C |
| Storage Temperature | -20 to +55 °C |
| Relative Humidity | 5% – 95% (non-condensing) |
| Housing Material | PC (front) / PC+ABS (rear), halogen-free |
| Weight | 62 g |
| KNX Interface | Integrated KNX BCU (TP1-256), supports KNX Data Secure |
| Certifications | CE, RCM |
Note
Continuous RGB backlighting may slightly influence the accuracy of the internal temperature sensor. For optimal performance, ensure the configuration matches the installation environment.
