theMura P180 KNX UP WH – PIR motion detector, 2 light & 2 HVAC channel

Name: Theben theMura P180 KNX UP WH – PIR motion detector, 2 light & 2 HVAC channel
Brand: Theben
Price: 93.42 EUR
Availability: OutOfStock
Rating: 0 (0 reviews)

0 Review(s)

€93,42 Excl. tax €162,48 Excl. tax
€113,04 Incl. tax €196,60 Incl. tax. Out of stock, but available

Unit price: €93,42 / Piece

Wall-mounted presence detector with 170° coverage, 2 light and 2 HVAC channels, integrated sensors and KNX Data Secure. Suitable for flexible lighting and climate control. Read more

Specifications

Brand:

Theben

Article number:

2069655

EAN:

4003468200339

Availability:

Out of stock, but available

Delivery time:

Dispatched within approximately 8 working days (please note: this is an estimate and depends on availability from the manufacturer; in some cases, it may be dispatched sooner, but it can also take longer).

Information

Link to Theben website

theMura P180 KNX UP WH

Presence detector with 2 light and 2 HVAC channels,

Art. no.: 2069655

Application

This passive infrared presence detector for flush wall mounting is designed for KNX building automation and offers advanced detection and control of lighting and climate systems in offices, corridors, meeting rooms and other commercial buildings.

Features

Rectangular detection area of 170°, up to 14 x 17 m (238 m²) at 1.1 m mounting height
2 light channels and 2 HVAC channels, fully KNX compatible
KNX Data Secure for increased system security
Switching or constant light control with standby function (orientation light)
Dimmable lighting when switching, with or without daylight influence
Easy correction of brightness measurement
Short presence and selectable control speed
Aura function and scene functions for flexible building management
Integrated orientation light (white)
Integrated temperature sensor and acoustic function
2 binary inputs for external switches or sensors
6 logic channels (AND, OR, XOR) for complex automation
Limited configuration via theSenda B (app/universal remote control) and theSenda P (service remote control)
Optional user remote control (theSenda S/B) for manual override
Fully or semi-automatic operation possible
Integrated freely configurable button (can be deactivated)
Manual override via external KNX button possible
Targeted brightness measurement (mixed light measurement)
Learning function and blocking functions
HVAC channel without brightness influence, switch-on delay and follow-up time adjustable
Extension of detection area possible via master/slave or master/master parameters
Adjustable detection sensitivity and test mode for verification
Configuration via ETS software (full functionality)
Detection area limitation strips included
Compatible with Theben cover frames and many standard switch ranges (with accessories)

Technical Specifications

Brightness measurement range	5 - 3000 lx
Mounting type	Wall mounting (flush-mounted)
Detection area	Rectangular, 170°, 14 x 17 m (238 m²) at 1.1 m height
Light follow-up time	30 seconds - 60 minutes
Type of light measurement	Mixed light measurement
Presence follow-up time	10 seconds - 120 minutes
Ambient temperature	-15°C to +45°C
Color	White
Protection class	IP 20
KNX Data Secure	Yes
Light channels	2
HVAC channels	2
Binary inputs	2
Logic channels	6 (AND, OR, XOR)
Orientation light	Integrated (white)
Temperature sensor	Integrated
Acoustic function	Yes
Mounting accessories	Compatible with various switch ranges (accessories)

Important Notes

Full functionality only configurable via ETS software.
Limited local control via remote control theSenda B/P or user remote theSenda S/B possible.
Indoor use only (IP20), not suitable for damp environments.
Detection area limitation strips are included for adjustment.
Accessories may be required for integration into switch ranges.
Mounting height and positioning affect detection area and performance.
KNX Data Secure ensures secure communication within the KNX network.
