Presence and motion detectors

KNX optical sensor set for ceiling surface mounting, 24V DC. Includes optical sensor, PIR unit and surface frame. Rectangular detection, light/presence control, temperature sensor.

Ceiling-mounted presence detector with 360° detection, up to 64 m² for presence and 400 m² for motion. Features sensors for light, temperature, humidity, and CO2.

The glass presence detector detects movements with 3 pyro sensors and a high-resolution lens. The version with constant light control has a range of 11 m. Both versions have an integrated temperature sensor.

Multisensor for KNX room control with presence detection, lighting management, temperature and humidity sensing, sound monitoring, and occupancy and space usage monitoring. Includes BLE beacon for location-based and app-driven functions.

KNX presence detector with standard functions, lighting control and integrated BLE beacon for smart interaction via mobile devices. Ideal for energy-efficient detection, automation and hotel or access management.

The IS 3360 KNX IP54 is a robust motion and presence detector with 360° coverage and 20 m range. Suitable for indoor and outdoor use, ideal for car parks, halls and entrances. Available in round or square design, white or black.

Elegant Steinel sensIQ S motion detector with 4 pyro sensors, 300° detection angle and 20 m range. For indoor/outdoor wall mounting, incl. remote control and KNX integration.

PIR motion detector for flush wall mounting with 170° detection, 14x17 m range. 1 light and 1 HVAC channel, dimmable, KNX Data Secure, ETS-compatible.

Ceiling-mounted sensor with an 8m detection range and a maximum mounting height of 2m. KNX-certified, with logic functions and master-slave capabilities. Operates at -5°C to 45°C with a bus voltage of 21-30V DC.

Compact KNX ceiling sensor with 360° detection up to 50 m², Ø8 m diagonal, mounting height 3–5 m. Black, opal-matte. Manual control and advanced KNX functions. IP55, Ø33 mm.

KNX ceiling presence detector with 360° range up to Ø24m, 2 light and 2 presence channels, adjustable light measurement and versatile automatic functions. IP54.

The Presence Detector MR16 with 3 sensors, temperature sensor, and LED night light. Detects small movements, with a range of 11m and 5m for presence. Advanced light and HVAC functions.

Ceiling presence detector with 360° detection up to 8 m, daylight-dependent constant light control, 2 lighting channels, 1 HVAC channel, manual operation. White (RAL9010) or black (RAL9005).

Ceiling sensor with daylight control, ESY pen and ESY app. KNX features: alarm, twilight switch, brightness detection, motion, scene telegrams.

PIR presence detector for ceiling mounting, 360° coverage up to 100 m², 3 light channels, 2 presence channels. Available in white, grey and black.

Motion detector with 2 sensors and temperature sensor. For wall mounting at 2.2 m. Suitable for 55 mm switches. Includes day/night function, light and alarm channels. KNX Secure with integrated bus coupler.

Advanced KNX multisensor for presence, light, temperature, humidity and acoustics. Includes constant light control, HVAC, alarm, twilight switch, scene control, light-based detection and 7-colour night light function.

KNX ceiling presence detector with 360° range up to Ø9m, automatic light and presence control, mixed light measurement, IP54. Available in white, grey, and black.

Flush-mounted KNX presence detector with 360° coverage up to 64 m², flat design, light and HVAC control, eco plus function and scene support.

This micro presence detector with motion and temperature sensors will be available from Q1 2025. Suitable for hollow wall installation, with a range of 5 meters and adjustable sensitivity for day, night, and presence.

Discreet flush-mounted KNX 360° PIR detector for motion and presence. Features light and temperature sensors, constant light control, 6 channels and master/slave. Ideal for lighting and HVAC control.

Compact KNX ceiling presence detector with 360° detection and 12 m range. Supports daylight control, alarm, and light functions. Suitable for ceiling flush mount.

KNX ceiling flush-mounted presence detector, 360° detection up to Ø9m, automatic light and presence control, mixed light measurement, dimmable, IP54, white.

HF presence detector for indoor recessed installation. 360° detection, up to 12 m reach, 4 KNX channels. Detects movement through glass, wood and walls. Ideal for washrooms, kitchens and stairwells.
